Name: Surrounding_RC

Display Field: STREET_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The Virginia Geographic Information Network (VGIN) has coordinated and manages the development of a consistent, seamless, statewide digital road centerline file with address, road name, and state route number attribution, as part of the Virginia Base Mapping Program (VBMP). The Road Centerline Program (RCL) leverages the Commonwealth's investment in the VBMP digital orthophotography and is focused on creating a single statewide, consistent digital road file. The RCL data layer is a dynamic dataset supported and maintained by Virginia's Local Governments, VDOT, and VGIN. VBMP RCL is extracted and provided back to local governments and state agencies in many geographic data sets every quarter.

Copyright Text: Virginia Geographic Information Network (VGIN), Virginia Department of Transportation (VDOT), Virginia local government GIS

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8557107.1392
YMin: 4367313.5383
XMax: -8415297.8058
YMax: 4542700.068099998
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: MTFCC
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: S1100
  Label: LIMITED ACCESS HIGHWAYS; HIGH OCCUPANCY VEHICLE (HOV) LANES; US AND VA PRIMARY HIGHWAYS; LIMITED ACCESS HIGHWAY FRONTAGE
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [204, 204, 204, 255]
  Width: 2
• Value: S1100HOV
  Label: LIMITED ACCESS HIGHWAYS; HIGH OCCUPANCY VEHICLE (HOV) LANES; US AND VA PRIMARY HIGHWAYS; LIMITED ACCESS HIGHWAY FRONTAGE
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [204, 204, 204, 255]
  Width: 2
• Value: S1200PRI
  Label: LIMITED ACCESS HIGHWAYS; HIGH OCCUPANCY VEHICLE (HOV) LANES; US AND VA PRIMARY HIGHWAYS; LIMITED ACCESS HIGHWAY FRONTAGE
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [204, 204, 204, 255]
  Width: 2
• Value: S1640
  Label: LIMITED ACCESS HIGHWAYS; HIGH OCCUPANCY VEHICLE (HOV) LANES; US AND VA PRIMARY HIGHWAYS; LIMITED ACCESS HIGHWAY FRONTAGE
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [204, 204, 204, 255]
  Width: 2
• Value: S1200LOC
  Label: LOCAL MAIN ARTERIES; LOCAL SECONDARIES; ALLEYS; SERVICE VEHICLE PRIVATE DRIVES
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 4
• Value: S1400
  Label: LOCAL MAIN ARTERIES; LOCAL SECONDARIES; ALLEYS; SERVICE VEHICLE PRIVATE DRIVES
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 4
• Value: S1730
  Label: LOCAL MAIN ARTERIES; LOCAL SECONDARIES; ALLEYS; SERVICE VEHICLE PRIVATE DRIVES
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 4
• Value: S1740
  Label: LOCAL MAIN ARTERIES; LOCAL SECONDARIES; ALLEYS; SERVICE VEHICLE PRIVATE DRIVES
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 4
• Value: S1630
  Label: RAMPS
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [204, 204, 204, 255]
  Width: 2
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [121, 123, 125, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: baseline
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 9
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 5000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• RCL_ID ( type: esriFieldTypeDouble, alias: RCL_ID )
• LOCAL_ID ( type: esriFieldTypeDouble, alias: LOCAL_ID )
• VDOT_EDGE_ID ( type: esriFieldTypeDouble, alias: VDOT_EDGE_ID )
• MFIPS ( type: esriFieldTypeString, alias: MFIPS, length: 7 , Coded Values: [51001: ACCOMACK COUNTY] , [51003: ALBEMARLE COUNTY] , [51510: ALEXANDRIA CITY] , ...178 more... )
• GEOMETRY_EDIT_TYPE ( type: esriFieldTypeSmallInteger, alias: GEOMETRY_EDIT_TYPE , Coded Values: [1: SEGMENT ADDITION] , [2: CARTOGRAPHIC LOCATION CHANGE] , [3: SEGMENT SPLIT] , ...5 more... )
• GEOMETRY_EFFECTIVE_DATE ( type: esriFieldTypeDate, alias: GEOMETRY_EFFECTIVE_DATE, length: 8 )
• GEOMETRY_SOURCE ( type: esriFieldTypeString, alias: GEOMETRY_SOURCE, length: 4 , Coded Values: [VGIN: VIRGINIA GEOGRAPHIC INFORMATION NETWORK] , [VDOT: VIRGINIA DEPARTMENT OF TRANSPORTATION] , [USCB: U.S. CENSUS BUREAU] , ...2 more... )
• GEOMETRY_EDIT_DATE ( type: esriFieldTypeDate, alias: GEOMETRY_EDIT_DATE, length: 8 )
• LEFT_FROM_ADDRESS ( type: esriFieldTypeInteger, alias: LEFT_FROM_ADDRESS )
• LEFT_TO_ADDRESS ( type: esriFieldTypeInteger, alias: LEFT_TO_ADDRESS )
• RIGHT_FROM_ADDRESS ( type: esriFieldTypeInteger, alias: RIGHT_FROM_ADDRESS )
• RIGHT_TO_ADDRESS ( type: esriFieldTypeInteger, alias: RIGHT_TO_ADDRESS )
• ADDRESS_RANGE_FORMAT ( type: esriFieldTypeString, alias: ADDRESS_RANGE_FORMAT, length: 1 , Coded Values: [A: ACTUAL ADDRESS RANGE] , [T: THEORETICAL ADDRESS RANGE] )
• ADDRESS_RANGE_SOURCE ( type: esriFieldTypeString, alias: ADDRESS_RANGE_SOURCE, length: 4 , Coded Values: [VGIN: VIRGINIA GEOGRAPHIC INFORMATION NETWORK] , [VDOT: VIRGINIA DEPARTMENT OF TRANSPORTATION] , [USCB: U.S. CENSUS BUREAU] , ...2 more... )
• ADDRESS_RANGE_EDIT_DATE ( type: esriFieldTypeDate, alias: ADDRESS_RANGE_EDIT_DATE, length: 8 )
• STREET_PREMODIFIER ( type: esriFieldTypeString, alias: STREET_PREMODIFIER, length: 10 , Coded Values: [ACCESS: ACCESS] , [ALTERNATE: ALTERNATE] , [BUSINESS: BUSINESS] , ...13 more... )
• STREET_PREFIX_DIRECTION ( type: esriFieldTypeString, alias: STREET_PREFIX_DIRECTION, length: 2 , Coded Values: [N: NORTH] , [S: SOUTH] , [E: EAST] , ...5 more... )
• STREET_NAME ( type: esriFieldTypeString, alias: STREET_NAME, length: 75 )
• STREET_SUFFIX ( type: esriFieldTypeString, alias: STREET_SUFFIX, length: 4 , Coded Values: [ALY: ALLEY] , [ANX: ANEX] , [ARC: ARCADE] , ...199 more... )
• STREET_SUFFIX_DIRECTION ( type: esriFieldTypeString, alias: STREET_SUFFIX_DIRECTION, length: 2 , Coded Values: [N: NORTH] , [S: SOUTH] , [E: EAST] , ...5 more... )
• STREET_POSTMODIFIER ( type: esriFieldTypeString, alias: STREET_POSTMODIFIER, length: 10 , Coded Values: [ACCESS: ACCESS] , [ALTERNATE: ALTERNATE] , [BUSINESS: BUSINESS] , ...13 more... )
• STREET_NAME_FULL ( type: esriFieldTypeString, alias: STREET_NAME_FULL, length: 100 )
• STREET_NAME_SOURCE ( type: esriFieldTypeString, alias: STREET_NAME_SOURCE, length: 4 , Coded Values: [VGIN: VIRGINIA GEOGRAPHIC INFORMATION NETWORK] , [VDOT: VIRGINIA DEPARTMENT OF TRANSPORTATION] , [USCB: U.S. CENSUS BUREAU] , ...2 more... )
• STREET_NAME_EDIT_DATE ( type: esriFieldTypeDate, alias: STREET_NAME_EDIT_DATE, length: 8 )
• MTFCC ( type: esriFieldTypeString, alias: MTFCC, length: 10 , Coded Values: [S1100: LIMITED ACCESS HIGHWAYS] , [S1100HOV: HIGH OCCUPANCY VEHICLE (HOV) LANES] , [S1200PRI: US AND VA PRIMARY HIGHWAYS] , ...14 more... )
• SEGMENT_TYPE ( type: esriFieldTypeSmallInteger, alias: SEGMENT_TYPE , Coded Values: [1: AIRPORT ROAD] , [2: BRIDGE/OVERPASS] , [5: GATE] , ...8 more... )
• LOCAL_SPEED_MPH ( type: esriFieldTypeSmallInteger, alias: LOCAL_SPEED_MPH )
• DUAL_CARRIAGEWAY ( type: esriFieldTypeString, alias: DUAL_CARRIAGEWAY, length: 1 , Coded Values: [Y: YES] , [N: NO] )
• ONE_WAY ( type: esriFieldTypeString, alias: ONE_WAY, length: 2 , Coded Values: [B: BI-DIRECTIONAL] , [FT: WITH SEGMENT ARC DIRECTIONALITY] , [TF: AGAINST SEGMENT ARC DIRECTIONALITY] , ...1 more... )
• REVERSIBLE ( type: esriFieldTypeString, alias: REVERSIBLE, length: 1 , Coded Values: [Y: YES] , [N: NO] )
• SEGMENT_EXISTS ( type: esriFieldTypeString, alias: SEGMENT_EXISTS, length: 1 , Coded Values: [Y: YES] , [N: NO] )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
